2.620m Automatic Lawn Mower

Product features

* with automatic tool grinding function, to solve the problem of time-consuming and laborious users, greatlyreducing maintenance time, improve efficiency.

* The vertical cylinder feeding device can adapt to the harvest of high straw crops such as corn andsorghum.

* The four-roll forced sequential feeding device can feed the cut-off material into the material choppingdevice in good order.

* The spray cylinder is rotated by worm gear and worm mechanism, and can rotate ± 180 °, effectivelylocking the spray cylinder angle, making the spray angle more stable.

* The material chopping device can realize the adjustable length of the material chopping, so as to meet the

needs of different forage forage harvesting.

* The cutting device adopts double disc saw blade, the material cutting is accurate and stable, and thestubble left is even and consistent.

* The throwing device can quickly and accurately throw the chopped material into the accompanying

material.

  Contact Now E-Mail Telephone WhatsApp
Product Details
Product introduction

Senrui farming and animal husbandry equipment 4QX-2800(yellow) green fodder harvester, harvester, the design is unique, novel, the equipment is suitable for crop height 400-5000mm, productivity 15-30t/h, efficient harvesting also helps to improve the overall benefits of agricultural production, promote the development of modern agriculture, vertical cylinder feeding device, can adapt to high straw crops such as corn, sorghum harvest, 4QX -2800 green fodder harvester can cut off the green fodder crops in one time, feed them in sequence, cut them up evenly, throw and load them

2.620m Automatic Lawn Mower  2.620m Automatic Lawn Mower

Product parameter:

Projects

unit

design value

Model Name

/

4QX-2800 type backpack green fodder   harvester

Form of Construction (Hook-up)

/

Suspension

Working condition external dimensions   (L*W*H)

mm

5868*2870*4890

structural quality

kg

1950

Matching power range

kW

117.6~154.35

Effective harvesting width of the cutter

mm

2620

Crop collection cutter type

/

Straight cutting table

Cutting table cutter type

/

Disc cutter

Feeding mechanism type

/

Feed rollers

Number of institutions fed

/

2 pair

Chopping mechanism rotor diameter

mm

1000

Rated spindle speed

r/min

850-1000

Maximum throwing height

mm

5500

Throwing Minimum Height

mm

3500

Swivelling angle of throwing cylinder

/

±180

Throwing maximum horizontal distance

m

12

Operating speed range

km/h

≤7

Mean geometric height of material

mm

20

Standard Grass Length Ratio

%

95

Number of moving knives

Piece

12

operating method

/

fully hydraulic

Adaptation to crop height

mm

400-5000

efficiency of production

t/h

15~30
