2.020m Best Self Propelled Forage Harvester
Product characteristics：
● Fuselage is short, small turning radius, flexible and convenient operation, suitable for small and medium-sized plots, mountains, hills, terraces and other areas of operation.
● Cut off the feeding assembly: two rolls feeding into the room, segmented design, more convenient maintenance, using double disc saw blade cutter, can adapt to all the stalk forage crops misoperation.
● Cutting assembly: cutter cutting device, to achieve multi-stage adjustable forage cutting length.
● nozzle assembly: nozzle rotation using the worm wheel worm mechanism, can ± 180 rotation, effectively lock the nozzle Angle, make the spray Angle more stable.
● Box assembly: with its own loading box, rollover unloading operation is simple, increase the secondary lifting function, better adapt to a variety of material receiving models, unloading more convenient.
● Power train: 160 horsepower engine, horsepower, power, four-wheel drive system, mountainous and hilly areas with high pass.
● Control: suspension seat, driving more comfortable.
4QZ-2000 green feed harvester, can be the harvest operation. The equipment is small in size, high efficiency, wide use, less energy consumption, dexterous action, not subject to crop spacing constraints, high operation efficiency and safe and reliable performance, can once for green (yellow) storage crops cut off the ground, sequential feeding, uniform cutting, throwing loading and other operations.
Projects | Unit | Design value |
Model Name | / | 4QZ-2000 self-propelled forage harvester |
Formality | / | Self-propelled |
Working condition external dimensions (L*W*H) | mm | 5200*2200*4000 |
Structural quality | kg | 3950 |
Matching Engine Rated Power | kw | 118 |
Matching engine rated speed | r/min | 2400 |
Cut width (of a page) | mm | 2020 |
Crop collection cutter type | / | Straight cutting table |
Cutting table cutter type | / | Disc cutter |
Feeding mechanism type | / | Feed rollers |
Number of institutions fed | / | 1 pair |
Chopping mechanism type | / | Disc |
Transmission mode | / | Manual gearbox |
Drive method | / | Mechine |
Brake type | / | Drum |
Guide wheel spacing | mm | 1180 |
Guide wheel tyre specifications | / | 10.0/80-12 |
Driving Wheel Distance | mm | 1230 |
Driving wheel tyre specifications | / | 11.5/80-15.3 |
Wheelbases | mm | 2190 |
Operating speed range | km/h | ≤6 |
Design Cutting Length | mm | 20 |
